Heavy Duty Stationary Scissor Lift Tables – Over 6 Tons

Basic Info

Heavy-Duty Design: Built for robust performance.
Capacity: Ranges from 6 to 12 tons with a single scissor mechanism.
Safety Guard: Equipped with a protective safety guard.
Anti-Explosion Valve: Includes an anti-explosion valve for added safety.
Customization: Special customer requirements are welcome.
Standards Compliance: HW series lift tables comply with EN norms and ANSI/ASME safety standards.
Versatile Applications: Suitable for both above-floor and in-floor pit installations.

Safety Bar: The upper platform has an aluminum safety bar that prevents descent upon contact with obstacles.
Control Box: Features a low-tension (24V) control box with up and down buttons.
Power Pack: Internal power pack includes a relief valve to prevent overload and a compensated flow valve for controlled lowering speed.
Heavy-Duty Cylinders: Equipped with a drainage system and check valve to stop the lift table from lowering in the event of a hose burst.
Safety Clearance: Designed with space between scissors to prevent trapping during operation.

Self-Lubricating Bushings: Located on pivot points to reduce maintenance.
Removable Lifting Eye: Facilitates handling and installation.
Optional Protection Curtain: Available for enhanced safety.
Additional Accessories: Various optional accessories can be provided as needed.
