Portable Mini Table Lift Platform
A Small Lift That Handles Big Jobs
With low collapsed heights and small platform sizes, these small work tables are ideal for smaller lift applications or cramped warehouses with limited floor space. The Compact Lift is available with unlimited possibilities for customizing these scissor lifts for a wide range of specialized applications.
Portable Mini Table Lift Platform
Models & Specs
| Travel | 36 in |
| Capacity | 4000 lbs |
| Height | 7 in (lowered) – 43 in (raised) |
| Base Frame Width | 23 in |
| Base Frame Length | 47 in |
| Platform Width | 23 in – 44 in |
| Platform Length | 47 in – 68 in |
| Max End Load | 2000 lbs |
| Max Side Load | 1000 lbs |
| Raising Time | 30 secs |
| Lowering Time | 10 secs |
| Power Unit | 1HP |
| Power Unit Location | Internal |
| No. of Cylinders | 1 |
| Shipping Weight | 825 lbs |
Portable Mini Table Lift Platform
Custom Options
Customize Your Lifts
Specifically sized, configured, mobile, high-cycle, or automated – when you need a lift to perform a specific function, we have the materials, components, and design techniques to produce a one-of-a-kind lifting solution for your application.
Portable Mini Table Lift Platform
Features & Benefits
Flexibility and Ease of Use
- More models and standard options than any other competitive lift table allow for easy customization to meet your specific needs.
- Standard controls are prewired and the internal power unit is onboard. Installation simply includes lagging the lift to the ground and connecting electricity.
- Exceptionally low height allows on and off-load flexibility.
- Single-piece, steel-reinforced legs and a 1/4- to 3/8-inch-thick steel platform make for extremely solid construction and easy adaptability.
Durability and Quality
- Joints, the most critical wear points in the lift, feature chrome-plated, 100,000 psi, ultimate-strength pins for premium load strength and long life.
- Solid steel leg and added stiffeners provide optimal overall stability and straight, repeatable tracking of the rollers as the lift raises and lowers.
- Minimum 1/4-inch-thick steel-reinforced platform minimizes deck deflection, maximizes load stability, and greatly extends the life of the platform deck.
Maintenance and Warranty
- On-board maintenance devices enable maintenance crews to safely and effectively block open the scissors during inspection and routine maintenance.
- Sturdy, semi-transparent polyurethane oil reservoir provides an easily visible method of checking fluid levels and eliminates oil contamination due to rust.
- Double-wire braided Parker hydraulic hoses resist wear, abrasion, and leaks.
- Easy replacement of high-strength steel rollers minimizes downtime.
- Gradin offers an industry-best 2-year warranty on all parts as a promise that you’ve purchased the industry’s most reliable lift.
Safety
- The flow control valve regulates the flow of fluid to control the speed of the lift as it is lowered.
- Minimum 3:1 structural factor of safety makes these lifts the most structurally sound lift in the industry.
- Compliance with recognized standards:
- ANSI MH29.1 – Safety Requirements for Industrial Scissor Lifts
- NFPA 70 – National Electric Code
- ASTM – A36 – Structural Steel Standard
- ANSI Z535 – Safety Labeling Requirements
- AWS D.1 – Welding Standards
- Applicable portions of OSHA 29CFR1910 – General Workplace Safety
| LIFT CAPACITY | |
|---|---|
| TRAVEL DISTANCE | ≤ 1 m |
| PLATFORM WIDTH | 1 – 2 m |
| PLATFORM LENGTH | 1 – 3 m |
